FLIPSKY Mini V6 MK5 VESC with Power Button
Features:
VESC_6_MK5 Platform
Smart Switch Function
Versatile Shutdown Modes
Enhanced Rotor Position Accuracy
The FLIPSKY Mini V6 MK5 With Power Button is a cutting-edge motor controller based on the VESC_6_MK5 platform, Moreover, featuring an aluminum anodized heat sink for superior thermal management. With its firmware version 6.02, which is upgradeable for continued optimization, and hardware version VESC_6_MK5, as a result, this controller offers top-of-the-line performance and reliability.
Delivering a continuous current of 70A and able to handle instantaneous currents of up to 200A, therefore, this controller ensures ample power for a wide range of applications. Its voltage compatibility spans from 14V to 60V, hence, accommodating battery configurations ranging from 4S to 13S. However, it's crucial to note that voltage spikes must not exceed 60V to maintain safe operation.
Equipped with a 5V BEC output providing 1A of power, in addition, the FLIPSKY Mini V6 MK5 With Power Button supports various control interface ports, including USB, CAN, and UART, enabling seamless connectivity and communication with external devices. Compatible with ABI, HALL, AS5047, and AS5048A sensors, furthermore, this controller offers precise control and feedback for enhanced performance.
Support for multiple input sets, such as PPM, ADC, NRF, UART, SPI, and IIC, ensures flexibility in control methods to suit different applications. Operating modes include DC, BLDC, and FOC (sinusoidal), thus offering versatility in motor control strategies.
With regenerative capacity and programmability, consequently, this controller maximizes energy efficiency and allows customization of settings to meet specific requirements. Additionally, its built-in phase filter ensures smooth motor operation, while the self-resetting on/off button, featuring a 16mm diameter, provides convenient control.
Constructed with 12AWG motor and power wires, as a result, the FLIPSKY Mini V6 MK5 With Power Button is engineered for durability and reliability, making it the ideal choice for electric vehicle and robotics enthusiasts seeking high-performance motor control solutions.
If you're planning to build a combat robot, be sure to check out our recommended setup blog.
Specs:
Firmware Version: 6.02(upgrade supported)
Firmware: 60_MK5
Hardware Version: VESC_6_MK5
Continuous current: 70A
Instantaneous current: 200A
Voltage: 14V-60V(Cells: 4-13S; safe for 4S to 12S, voltage spikes may not exceed 60V! )
BEC: 5V@1A
Control Interface Ports: USB,CAN,UART
Supported Sensors: ABI, HALL, AS5047, AS5048A
Input Set Support: PPM, ADC, NRF, UART, SPI, IIC
Modes: DC, BLDC, FOC (sinusoidal)
Regenerative capacity: Yes
Programmable: Yes
Phase Filter: Yes
On/off Button: self-resetting; Switch Diameter: 16mm
Motor wire: 12AWG
Power wire: 12AWG
Size: 67x39x18.7mm (Including heatsink)
Important Notice:
This VESC has undergone thorough testing to ensure its functionality and performance. Please be aware that any issues arising from its use, such as overheating or MOSFET failure, are the sole responsibility of the customer. We do not assume liability for any damages or malfunctions after the product has been delivered in tested condition.
Upgraded Features:
Mini V6 MK5 is developed based on VESC_6_MK5, it adds phase filter circuit which can obtain more accurate
rotor position information at low speeds.
It’s integrated with smart switch function, supports manual power on/off, roll to start, auto turn off and led
indicates state.
Support four shutdown modes: ALWAYS_OFF, ALWAYS_ON, TOGGLE_BUTTON_ONLY, and OFF_AFTER_.
Package Includes:
1 x FLIPSKY Mini V6 MK5 VESC
1 x USB Cable
1 x Connector Cable
1 x User Manual Page
