MABUCHI DC Motor 775 Powerful High Speed 24V Motor
₹1,499.00
Features:
- High Speed: Provides rapid rotation for efficient performance.
- High Power: Delivers ample power for various applications.
- Large Torque: Generates strong force for demanding tasks.
- Voltage Range: Operates efficiently within a range of 12V to 18V.
- Reliable Brand: Manufactured by MABUCHI, known for quality motors.
Price Info
Price including GST Choose Quantity
Product Details
The MABUCHI RS-775WC-8514 12V-18V Motor is a powerhouse of performance, designed to meet the demands of high-speed and high-power applications.
With a maximum speed of 17,040 revolutions per minute (r/min) and a maximum current of 18.7 Amperes (A), it ensures swift and efficient operation across various tasks.
Its impressive torque capabilities, reaching up to 153 milliNewton-meters (mN.m) or 1561 gram-centimeters (g.cm), provide ample rotational force for demanding projects.
With an output of 273 Watts (W), this motor delivers consistent and reliable performance, making it an excellent choice for robotics, automotive, and industrial applications where large torque and high-speed operation are essential.
If you're planning to build a combat robot, be sure to check out our recommended setup blog.
Specs:
- Operating Range Voltage (V): 6 - 20
- Nominal Voltage (V): 18
- No Load Speed (r/min): 19500
- No Load Current (A): 2.7
- Max Speed (r/min): 17040
- Max Current (A): 18.7
- Max Torque (mN.m): 153
- Max Torque (g.cm): 1561
- Output (W): 273
- Stall Torque (mN.m): 1216
- Stall Torque (g.cm): 12400
- Stall Current (A): 130
- Motor Length (mm): 84.5
- Motor Diamater (mm): 42
- Shaft Length (mm): 17
- Shaft Diameter (mm): 5
Drawing:
Package Includes:
1 x MABUCHI DC Motor 775 Powerful High Speed 24V Motor
