READYTOSKY-2-3S BRUSHLESS ESC - 30a
Features:
Battery Support: Works with 2S–3S LiPo batteries.
Motor Control: Stable and reliable brushless operation.
Built-in BEC: 5V linear BEC (1–2A typical).
Safety Features: Includes low voltage and overheat protection.
Throttle Response: Smooth and linear control.
Compact Design: Lightweight and easy to install.
Flight Controller Ready: Compatible with most FCs.
Quick Setup: Simple calibration process.
Durable Build: Made with long-lasting components.
Beginner Friendly: Great for RC and DIY projects.
Power your small to medium RC projects with the READYTOSKY 2-3S Brushless ESC. Designed for 2S-3S LiPo batteries, this Electronic Speed Controller provides reliable and smooth motor control. Ideal for beginner-friendly drones, fixed-wing aircraft, and various DIY RC applications, offering essential protection features for safe operation.
Specs:
Brand: READYTOSKY
Continuous Current: 30A
Burst Current (10 seconds): 35A – 40A
Input Voltage: 2–4S LiPo (7.4V – 16.8V)
BEC Output: 5V / 2A Linear BEC (used for powering flight controller or receiver)
Firmware: Likely compatible with SimonK or BLHeli_S (user confirmation needed for exact firmware)
Processor: Typically 8-bit MCU (e.g., Atmel ATmega8 or similar)
Throttle Signal Rate: Standard PWM up to 490Hz (not DShot unless BLHeli-based)
Dimensions: Approx. 52mm x 26mm x 9mm
Weight: Approx. 20g (may vary slightly depending on heat sink or connectors)
Input Wires: 16AWG silicone wire (no connector, user-soldered XT60 commonly used)
Output Wires: 16AWG silicone wire (no bullet connectors pre-attached)
Connector Type: No connectors included by default (user adds bullet or solder)
Protection Features:
Low Voltage Cutoff Protection
Over-temperature Protection
Throttle Signal Loss Protection
Design Type: OPTO (No BEC for some versions; linear BEC in others) — verify specific model
Package Details:
1x READYTOSKY 2-3S Brushless ESC (specific amperage model)
1x User Manual / Basic Wiring Diagram (often a small paper slip or digital)
